The NPS-W series, as a three-window display mini DC power supply, can simultaneously display voltage, current and power. This product overcomes the shortcomings of traditional linear power supplies that are bulky, heavy and inefficient.
Features:
LED 3-digit display of voltage, current and power, high precision with single channel output.
The DC power supply
Features?voltage stabilization, current limiting and simple operation.
Over voltage protection(OVP), over current protection(OCP) and over temperature protection.
Continuously adjustable output of voltage and current with fine regulating and coarse regulating.
Automatic conversion of voltage stabilizing and current stabilizing; adopt current limiting protection mode, and any external service state will not be damaged.
With replaceable fuse for safe use, convenient to change the fuse.
Applied in production line test, electrical maintenance, aging products, battery charging, laboratories scientific research and teaching, etc.
Specifications:
Color: White / Black (Optional)
Plug Type: AU / EU / US / UK (Optional)
Model: NPS605W
Output Voltage: 0~60V
Output Current: 0~5A
Output Power: 300W
WORKING ENVIRONMENT:
Input Voltage: AC 230V/115V +/- 10%; 50Hz/60Hz
Working Temperature: 0~40 celsius ; Relative Humidity: less than 80%RH
Storage Temperature: -10~70 celsius ; Relative Humidity: less than 70%RH
CONSTANT VOLTAGE CV:
Voltage Stability: 0.1% +/- 3mV
Load Stability: 0.2% +/- 3mV
Ripple Voltage: =0.5% Vp-p
0 to rated voltage continuously adjustable
CONSTANT VOLTAGE CC:
Current Stability: 0.1% +/- 3mA
Load Stability: 0.2% +/- 3mA
Ripple Current: =0.5% Vp-p
Recovery Time: =500Microsecond
Temperature Coefficient: =100ppm/ celsius
0 to rated current continuously adjustable
DISPLAY:
Three-window digital tube display: voltage, current, power
Display Accuracy: 0.5% +/- digits
Display Resolution: voltage 0.1V; current 0.01A; power 0.1W/1W
SIZE AND WEIGHT:
Item Size: Approx. 230 * 130 * 70mm / 9.06 * 5.12 * 2.76in
Item Weight: 1372g / 48.39oz
Package Weight: 1550g / 54.69oz
Package Size: Approx. 29 * 18 * 10.5cm / 11.42 * 7.09 * 4.14in
Package List:
1 * DC Power Supply
1 * Power Cord
1 * Alligator Clip Line
1 * User Manual (English)
