Features:
4 pole 12 slot hi-torque motor design,CNC machined 6061 T6 billet aluminum heatsink can.
High purity copper windings maximizes efficiency.
High RPM ABEC 5 oversized bearings.
Universal fit, fits all 1/8, 1/10 brushless cars,Precision balanced rotor, smoothness for best reliability and maxium RPM.?????
Stator- super thin 0.2mm laminations,Removalbe/replaceable rotor,Precision engineered for maxium energy coversion.
Specifications:
Item: 3660 Motor
Waterproof Level: Splash-proof
Watts: 1200W
Max voltage: less than 13V
Max Amps: 92A
KV(RPM/Volt): 3800KV
Max RPM: 50000
Diameter: 36mm
Length: 60mm
Shaft length: 17mm
Shaft diameter: 5.00mm
Plug type: 4mm golden banana plug
The 80A brushless ESC is built with the highest quality components to ensure high efficiency operation. It
Features enhanced throttle response.
excellent acceleration, strong breaks and throttle linearity, which is suit for 1/8 Remote?Control Car.
80A EscCompatible with sensorless brushless motors.
Super smooth and accurate throttle linearity.
Built-in high-efficient and high-power 5.8V/3A SBEC.
Enhanced throttle response, excellent acceleration, strong brakes and throttle linearity.
Mutiple protection
Features: low voltage cut-off protection for lithium or nickel battery, over-heat protection, throttle signal loss protection.
Item: 80A brushless ESC
Brand: Queen hobby
Continous current: 80A
Burst current: 480A/10sec
Power supply: 2-4S LiPo / 4-12S NiMh
BEC: 5.8V/3A
Power supply plug: T plug
Motor plug: 4mm banana connector
Replacement?for: 1/8 1/10 Remote?Control car
Cooling system: Cooling fan
Programmable: YES
Programming Card Replacement?for Remote?Control Car ESC Brushless Electronic Speed Controller
Light weight,Easy to use,Portable design
Programming Card for Remote?Control Car ESC Brushless Electronic Speed Controller, which
was specially designed for Brushless Electronic Speed Controller selled in our store.
Item: Programming Card
Low voltage cut off: 3.1V/Cell 2.8V/Cell 3.3V/Cell No cut-off
Start mode:Medium, soft, strong
Max brake force: 25%, 50%, 75%, 100%
Max reverse force: 25%, 50%, 75%, 100%
Neutral range: 6%, 9%, 12%, work state
Package Information:
Package Size: 9*7*5cm
Package Weight: 401g
General Box Package
Package?List:
1*??Brushless Motor
1*? ESC
1*? Programming Card
No-delivery refund
