This 2P energy meter has a higher definition interface, more accurate data display, more convenient operation, safer electricity use. Voltage, current, power, timing, electric energy, temperature, frequency and power factor 8in1 design, convenient for users to understand the use of electric energy, realize the visualization of electricity consumption. Standard guide rail installation, suitable for apartments, companies, shopping malls, hotels, family homes, and so on.
Features:
Premium Material: This energy neter is made of ABS and PC material, higher strength and toughness, higher temperature resistance, better overall performance.
Multicolor Screen Interface Design: New intelligent design, higher definition interface, more accurate data display, more convenient operation, safer electricity use.
Multifunctional Design: Voltage, current, power, timing, electric energy, temperature, frequency and power factor 8in1 design, convenient for users to understand the use of electric energy, realize the visualization of electricity consumption. And with poweroff memory function.
Guide Rail Slot Installation: Standard guide rail installation, no screws, snapon mounting, convenient and easy to install.
Wide Applications: Suitable for high and low power distribution cabinets, display cabinets and racks, factory assembly lines, corporate warehouses, rental apartments, companies, shopping malls, hotels, family homes, and so on.
APP Function (Only KWS302WF Support):
Cellphone Remote APP Control: Download SmartLife APP or graffiti intelligent APP connection, realize WIFI network cloud remote intelligent control. Where there is signal, you can control the device whenever and wherever you want, unlimited distance.
APP Timing Function: Countdown function, you can add multiple sets of time data in the mobilephone APP to set the power on.
Device Sharing: Share management, multiperson control, support a one cellphone to control multiple switches, at the same time you can share multiperson control.
Power Failure Protecting Function (KWS302WF and KWS302L Support): Support overvoltage, undervoltage, overcurrent, overpower, overtemperature, timer power failure protections setting, and screen hibernation setting.
Specifications:
Name: 8in1 Energy Meter
Material: ABS+PC+VO
Model: KWS302WF, KWS302L, KWS302 (optional)
Voltage measurement ranges: 170270V
Current measurement ranges: 063A
Power measurement ranges: 017KW
Timing measurement ranges: 0999Hrs
Electricity measurement ranges: 09999Kwh
Temperature rangeminus: 20150 celsius
Frequency measurement ranges: 5060Hz
Power factor: 0.001.00PF
Power failure memory: KWS302WF Yes, KWS302L Yes, KWS302 Yes
Undervoltage protecting: KWS302WF Yes, KWS302L Yes, KWS302 None
Overvoltage protecting: KWS302WF Yes, KWS302L Yes, KWS302 None
WIFI: KWS302WF Yes: KWS302L None, KWS302 None
Item size: 66 * 66 * 82mm 2.60 * 2.60 * 3.23in
Package size: 89 * 73 * 75mm 3.50 * 2.87 * 2.95in
Package weight:
KWS302: 182g 6.42ounce
KWS302L: 213g 7.51ounce
KWS302WF: 215g 7.58ounce
Packing List:
1 * 8in1 Energy Meter
