Description:
• DIGITAL DISPLAY :The digital display provides accurate temperature readings, making it easy to monitor and Switch the modes between cool and heat;Control temperature
setting the temperature setting value and the difference value;
Temperature calibration; Refrigerating control output delay protection; Alarm when temperature exceeds, temperature limit or when sensor error.
VERSATILE USAGE :This thermometer hygrometer is perfect for household use, making it ideal for use in your home or office.
Features:
• High quality ;Mini and light weight design; large and clear LCD display.
• Auto converts cooling and heating modes to keep your equipment in an ideal temperature range. .Have 2 relays .Switch between cooling and heating modes. Support celsius display.
• Wide temperature range (-50-99 °C); dual heating and cooling function.
• Refrigerating control output delay protection; With compressor delay protection function for refrigerating control.
• Control temperature by setting the temperature set value and the different value.
Technical Parameters:
1.Temperature measuring range: -50 ° C ~ 99 ° C 2.Resolution: 0.1 ° C;
3.Accuracy:+- 1° C (-50 ° C ~ 70 ° C);
4.Sensor error delay: 1 minute
5.Power supply: 110-220VAC 50/60Hz, 12Vdc , 24Vdc ( Choose power supply when you place order ) ;
6.Power consumption: <3W;
7.Sensor: NTC sensor (1PC);
8.Relay contact capacity: Two Relay Cool 10A/220VAC; Heat 10A/220VAC;
9.Ambient temperature: 0 ° C ~ 60 ° C;
10.Storage temperature: -30 ° C ~ 75 ° C;
11.Relative humidity: 20% ~ 85% (No condensate)
12.Sensor length: 1.0m
13. Front Panel Size: 75x34.5mm ;
Product Size: 75x34.5x85 mm ;
Mounting Size: 71x29mm
Menu Instruction:
Code Function Set Range Default
F1 Temperature set value -50.0~99.9°C 10.0°C
F2 Difference set value 0.3~10.0°C 0.5°C
F3 Compressor delay time 1~10 minutes 3 minutes
F4 Temperature calibration value -10.0°C~10.0°C 0°C
100% brand new and high quality modle: STC-1000 Switch the modes between cool and heat; Control temperature by setting the temperature setting value and the difference value;
Temperature calibration; Refrigerating control output delay protection; Alarm when temperature exceeds temperature limit or when sensor error.
