Feature:
1. The wire threaded sleeve is female thread fastener with certain elasticity, which can enhance the connection strength of the thread.
2. The thread size is standard, the thread is clear, and it will be more accurate for thread sliding tooth restoration.
3. 304 stainless steel has good corrosion resistance and is not easy to break when repairing thread holes.
4. The screw sleeve can be used to convert between metric and imperial thread holes, which is convenient and fast.
5. The repair nut is mainly used in aviation, automobiles, lamps, molds, mechanical equipment and other manufacturing fields.
Specification:
Item Type: Wire Thread Insert
Material: SUS304
Model: M10 x 1.5
Thread Specification: M10 x 1.5
Outside Diameter Before Installation: Approx. 1212.5mm 0.470.5in
Drill Bit Diameter: Approx. 10.5mm 0.4in
1D Length After Installation: Approx. 10mm 0.4in;
Number of Turns Before Installation: 5
1.5D Length After Installation: Approx. 15mm 0.6in;
Number of Turns Before Installation: 8.1
2D Length After Installation: Approx. 20mm 0.8in;
Number of Turns Before Installation: 11.2
2.5D Length After Installation: Approx. 25mm 1in;
Number of Turns Before Installation: 14.2
3D Length After Installation: Approx. 30mm 1.2in;
Number of Turns Before Installation: 17.3
Wire Thread Insert Model Description: For Example: M3 x 0.5 x 1.5D, which means that after the screw set is completed, the female thread is M3, the pitch is 0.5, and the length is 1.5D (length is 1.5 times the diameter, that is, 1.5 x 3=4.5mm ), the length here refers to the length after installation.
Wire thread inserts are also called threaded sheaths, stainless steel threaded sleeves, wire sleeves, and braces. They are a new type of internal threaded fasteners made of highstrength, highaccuracy diamondshaped crosssection steel wire; in aluminum alloy, zinc The application of lowstrength engineering materials such as alloys, copper, plastics can significantly improve thread strength and wear resistance..
Package List:
50 x Wire Thread InsertThe wire threaded sleeve is female thread fastener with certain elasticity, which can enhance the connection strength of the thread.
The thread size is standard, the thread is clear, and it will be more accurate for thread sliding tooth restoration.
304 stainless steel has good corrosion resistance and is not easy to break when repairing thread holes.
The screw sleeve can be used to convert between metric and imperial thread holes, which is convenient and fast.
The repair nut is mainly used in aviation, automobiles, lamps, molds, mechanical equipment and other manufacturing fields.
