Ayzeze: Please note that in most European countries the speed limit for electric scooters is 20 km/h.
-----
❗Purchase Notes❗
1. Some electric scooters come with a speed limiter by default. For instructions on how to remove or install the speed limiter, please refer to the relevant videos on YTube, depending on your brand and model.
2. We recommend using the speed limiter mode on public roads in urban areas. This mode has a maximum speed of 25 km/h, which is more compliant with traffic regulations and better ensures your personal and traffic safety.
3. This product does not include VMP or ABE certification. If you require these certifications, please do not place an order. If you place an order for this reason, we will not accept a refund request for that reason.
4. All speed figures refer to the maximum values measured under controlled laboratory conditions with a rider weight of 60–65 kg, a fully charged battery, and a flat road surface. Actual riding speed may vary depending on real-world conditions.
5. All range figures refer to extreme values measured under controlled testing conditions, including a rider weight of 60-65 kg, a fully charged battery, and riding at a constant speed on a flat surface. Actual range may vary depending on real-world conditions.
6. For any other questions, please scroll down on the product page and find the "ⓘ Seller Information and Responsibilities" button next to the store icon (website), or click the store icon and find "ⓘ About the seller" (APP), then obtain relevant information via ✉️ or Whats.
Model: KuKirin C1 Pro
📊Basic parameter
Product G.W:37kg
Product N.W:33kg
Expend size:1455*635*1100mm
Fold size:1455*700*680mm
Handlebar size:635mm
Pedal to Handlebar size:480*210mm
Chassis height:820mm
Pedal size:130mm
Max Load:120kg
Max speed:45km/h
Speed gear:1st、2nd、3rd(speed limit) 1 gear:23km/h、2 gear:33km/h、3 gear:50km/h
1st、2nd、3rd(65kg Load) 1 gear:20km/h、2 gear:30km/h、3 gear:45km/h
Middle speed mileage(65kg Load):≤100km
Performance Climbing ability:≤18° slope
Brake system:Front and rear disc brake&e-brake
Brake distance:7-10m
Waterproof level:IP54
Material Frame material:Iron frame
⚙️Motor
Motor type:Integral hub motor (rear wheel single drive)
Voltage:48V
Acclerate mode:Sine wave
Rated power:500W
Instantaneous maximum power:800W
Rated speed:588.4 rpm
Max output torque:35.84 N·m
🔋Battery
Model:18650 Lithoum battery
Voltage:48V
Single cell capacity:2600mAh
Battery pack capacity:26Ah
Standard power consumption KW.H:1.2 kW·h
Battery protect system:Battery protective board(BMS)
🔌Charger
Input voltage:100-240V~50/60Hz
Input current:3A Max
Output voltage:54.6V
Output current:3A
Charging time:8-9h
🛡️Shock absorber system
Front shock absorber:Front fork spring shock absorber
Rear shock absorber:/
💡Light System
Headlight type:LED
Headlight power:6W
Headlight illumination angle:45°
Headlight irradiation area:5㎡
Turn light:Yes
Taillight:"Yes,The taillights are on when the headlight is on, taillight flash when breaking."
🛞Tire
Size:14*2.125in
Type:Tubeless
Optimum tire pressure:240-310kPa(35-45psi)
🛑Disc brake disc
Outer diameter:/
Thread hole diameter:/
📱Instrument
Type:LED
Instrument material:ABS
Size:40*58mm
Show content:Speed, mileage, headlights, cruise, brakes, battery level, logo, gear position, etc.
Function setting:"1.Press and hold up and down buttons simultaneously for 3 seconds to enter or exit the parameter setting interface and save it. In the setting mode, short press the power button to switch to different parameters.
2.Press the power button 6 times in succession to switch the speed limit successfully: Speed limit 01 flashes 3 times, Unlimited speed 02 flashes 3 times.
P01 is the setting of non-zero start and zero start, 0=zero start, 1=non-zero start;
P02 speed limit value ratio, unit 30-100%, default 100;
P03 is the wheel diameter setting, unit, inches 40-400, default 140;
P08 is the automatic cruise function, 0 = no cruise, 1 = automatic cruise;
P09 Battery voltage selection: 24V, 36V, 48V, default 48V."
📦Package Information
Packing size:1200*250*600mm
Packing list:User manual*1,Charger*1,Hexagon socket*2, Wrench*1, Rearview mirror*2, Rear seat back*1, Front basket*1, Headlight*1, Quick release shaft*1; Seat*1, Seat tube*1
