AD8302 LF2.7G RFIF Phase Detection Impedance Analysis Module

Features: Measures GainLoss and Phase up to 2.7 GHz Dual Demodulating Log Amps and Phase Detector Input Range 60 dBm to 0 dBm in a 50 Ohm System Accurate Gain Measurement Scaling (30 mVdB) Typical Nonlinearity < 0.5 dB, Typical Nonlinearity < 1 Degree Accurate Phase Measurement Scaling (10 mVDegree) MeasurementControllerLevel Comparator Modes Operates from Supply Voltages of 3.3v~5V Stable 1.8 V Reference Voltage Output Small Signal Envelope Bandwidth from DC to 30 MHz APPLICATIONS: RFIF PA Linearization; Precise RF Power Control; Remote System Monitoring and Diagnostics; Return LossVSWR Measurements; Log Ratio Function for AC Signals Specification: Model: AD8302 Supply Voltages: 3.3v~5V Input Range : 60 dBm to 0 dBm( 50 Ohm ) Measures GainLoss and Phase : Max. 2.7 GHz Reference Voltage Output: 1.8 V Size: 5*3.5cm2*1.4in Weight: Approx.8g0.3oz Package list: 1 x AD8302 Amplitude Phase RF Detector

Measures GainLoss and Phase up to 2.7 GHz

Dual Demodulating Log Amps and Phase Detector

Input Range 60 dBm to 0 dBm in a 50 Ohm System

Accurate Gain Measurement Scaling (30 mVdB)

Typical Nonlinearity less than 0.5 dB, Typical Nonlinearity less than 1 Degree
