XL6009 Boost module DC-DC Power module Outputs an adjustable LM2577 4A current

Package : DIY Module

Model Number : XL6009 Dissipation Power : ... Supply Voltage : 3V-32V Application : Computer Type : Voltage Regulator

Origin : China Condition : New Operating Temperature : -40℃~+80℃ Functions : Electronic Module Range of application : Switch And Sensor For Arduino STM

Our products are independent research and development and production, sophisticated technology, each products are through strict test before sent to the user. And can meet the demand of batch. 32 V - 3.2 V input output highest 38 V Output voltage range: 4 v to 38 v dc voltage continuously adjustable, high efficiency (96%) of the maximum output current for 4 a. Advantage: use double thickening black oil PCB with high quality, all use imported SMD aluminum electrolytic capacitors, high Q value power inductors. And every piece of plate passes through the strict technical test, test completely using separate antistatic protection bag packaging.

Note: Does this modules relative to the LM2577 triode mode conversion efficiency is higher Does this module is adjustable booster module, can by adjusting the precision of modules above circle more adjustable potentiometer To change the output voltage. The highest output voltage is 38 v. Chronological booster, reverse-time step-down. Does the module above marked GND (input), the IN + (input), GND (output), the OUT + (output) Does working temperature: : industrial grade 40 to + 85 (-) (ambient temperature more than 40 degrees, please reduce power use, or enhance heat dissipation)
