Label:Yes
Minimum amplitude resolution can be up to 1mV.
Amplitude resolution: 1mV
Duty cycle of each channel can be adjusted separately. Precision can be 0.1%.
Waveform: Sine, Square, Triangle, Pulse (duty-cycle correction), Partia Sine, CMOS, DC level, Half-wave, Full-Wave, Pos-Ladder, Neg-Ladder, Noise, Exponential Rise, Exponential Fall, Tone, Sinc Pulse, Lorentz Pulse, and 60 kinds user defined waveform.
Full range of 0.01Hz frequency resolution.
Normal Modes & Square & Triangle Wave: 0~15MHz
Counting region: 0-4294967295
Counting mode: Manual operation
Advantage:
Counter Function:
Sawtooth & Arbitrary & TTL Digital Signal Wave: 0~6MHz
Measurement accuracy: Gate time continuously adjusted between 0.01S~10s
Frequency stability: ±1ppm×10-6/3h
Frequency accuracy: ±20ppm×10-6
High frequency precision up to 10-6 orders of magnitude.
Coupled mode: 2kinds Coupling modes, DC and AC
Amplitude stability: ±0.5%/5 h
Frequency Meter Function:
Amplitude flatness: ±5%(<10MHz); ±10%(>10MHz)
Product Description
Frequency measurement range: 1Hz~100MHz
Square rise time: ≤30nS
Package Included:
1 x DDS Signal Generator
1 x USB Cable
1 x Power Adapter
2 x Q9 Cable
1. High Precision: This signal generator offers high frequency precision up to 10-6 orders of magnitude, ensuring accurate and reliable results.
2. Versatile Functionality: With a full range of 0.01Hz frequency resolution and various waveform options including sine, square, triangle, and more, this signal generator can meet a wide range of testing and experimental needs.
3. Adjustable Duty Cycle: Each channel of this signal generator can have its duty cycle adjusted separately with a precision of 0.1%, allowing for precise control and customization.
4. Wide Frequency Range: This signal generator supports various waveforms with frequencies ranging from 0~15MHz for normal modes and square/triangle waves, and 0~6MHz for sawtooth/arbitrary/TTL digital signal waves.
5. Convenient Measurement Features: The signal generator also includes a frequency meter function for accurate frequency measurement in the range of 1Hz to 100MHz, as well as a counter function with manual operation for counting tasks.
