Description:
- High precision and quick reaction.
- With Large clear LCD display for easy to read
- Compact pocket size to take along
- Wide measuring range with high resolution
- 35°angle with 0.5HA/0.5HC/0.5HD resolution
- Material: Plastic and Alloy
Specification:
- On/off switch: power on and off
- H key: hold the reading
- Zero function: reset the readouts
- Range: 0-100HA/100HC/100HD
- Resolution: 0.5HA/0.5HC/0.5HD
- Accuracy: no more than ±1%
- Power:1.5 cell
- Working temperature: 0- 40℃
- Flat cone point: 0.79mm diameter
- Pressure needle top cone angle: 35°
- Total measure force: 8.1N
- Battery type: 1.5v
- Size: approx. 84x57x26mm/3.31x2.24x1.02inch
Size Chart:
Usage type:
Type A: for low hardness things, such as rubber, leather & wax
Type C: for rubber and platics that is made of the vesicant
Type D: for general hard rubber, hard resin, acryl, glass, thermoplastics, printing plates, fibres, etc.
How to use:
1.Press the needle vertically into the style
2.Pressure needle and sample contact safety within 1 second reading
3.Hardness values were measured 5 times in different (more than 6mm apart) and the average value was obtained.
Package Includes:
1 Piece of Digital shore hardness durometer
Note:
The color may have different as the difference display, pls understand.
Please allow 1-3mm error due to hand test.
