ABWR-F-75S HVLP Gravity Siphon Air Spray Gun With Regulator, Bottom Feed Paint Sprayer 44-73 PSI, 600Cc Cup Capacity

ABWR-F-75S HVLP Gravity Siphon Air Spray Gun With Regulator, Bottom Feed Paint Sprayer 44-73 PSI, 600Cc Cup CapacityEquipped with HVLP (High Volume Low Pressure) technology, this spray gun enhances material transfer efficiency, significantly reducing paint wastage and air consumption. Ideal for cost-effective painting, it ensures a smoother, high-quality finish with various materials. Features a robust stainless steel nozzle of approximately 1.5mm, designed for durability and resistance against wear and corrosion. The nozzle's detachable design facilitates easy cleaning and maintenance, ensuring long-term, reliable performance in various painting tasks. This versatile tool comes with three adjustable control knobs that regulate fluid and air flow, as well as spray patterns. These settings can be finely tuned to match the specific requirements of your project, whether you're working on automotive, industrial, or woodcraft applications. The gravity feed design of this spray gun supports a wide range of paints and finishes, including lacquers, basecoats, clear coats, and polyurethane top coats. Its 600cc cup capacity is ample for extensive projects, making it a reliable choice for professional and DIY painters alike. Designed for flexibility in application, the spray gun features a unique system that differentiates between upper and lower pots. The lower pot is ideal for horizontal or slight angle applications, while the upper pot can rotate for 360-degree spraying, accommodating a variety of painting angles and surfaces.

Specification:

Item Type: Spray gun

Material: Aluminum alloy

Capacity: 750ml

Paint Supply Method: Siphon

Working Pressure: 0.25-0.4 (Mpa)

Diameter of Spray Hole: Approx.1.5mm /0.1in

Air Connector Size: Approx. 1.1cm / 1/4inchPaint Spraying Volume: 435 (≥ml/min)

Effective Spray Distance: Approx. 20cm /7.87in

Air Consumption: Approx. 5-10 (l/min)

Scope of Application: Latex paint, primerand top coat spraying

Instructions:

1. Pour the well-proportioned paint intothe paint pot and connect it with the feed joint

2. Connect compressed air to the air inletconnector

3. Pull the trigger and adjust the properworking air pressure (3.5-4.5bar)

4. Adjust the amount of paint and spray width(adjust as needed)

5. Parallel and vertical spray on the cleansurface (spray distance is about 20cm) Color: Silver

Package Contents: 1* Pneumatic Paint Sprayer

Only the above package content, other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
